EMEA_PROMO_R570_SPL3

Dell PowerEdge R570 2U Rack Mount Server, Xeon 6507P 4.3GHz, 32GB RAM, 960GB SSD, 12x 3.5" bays

Dell PowerEdge R570 2U Rack Mount Server, Intel Xeon 6507P Granite Rapids 3.5GHz up to 4.3GHz 48MB Cache Eight 8x Core Processor with no intergrated Graphics, 32GB DDR5 ECC Memory, 960GB SATA Read Intensive 6Gbps 512e 2.5" Hot-Plug AG Drive, 12x 3.5" Chassis, PERC H965i Controller, Dual hotplug 1100W PSU, No opertaing system

Overview:

The Dell PowerEdge R570 is a 2U, one-socket rack server engineered for high-performance computing with exceptional power efficiency and balanced performance, driving cost savings and boosting data center productivity.

Description:

The Dell PowerEdge R570 is designed for businesses and data centers that need dependable computing performance in a compact 2U rack form factor. With an Intel Xeon 6507P processor, ECC DDR5 memory, hot-plug storage, a PERC H965i controller and dual 1100W hot-plug power supplies, this server provides a strong foundation for demanding workloads. Its scalable architecture also makes it suitable for virtualization, medium VM density, VDI, scale-out databases and software-defined storage.

Features:

Dell PowerEdge R570 2U Rack Server for Data Center Workloads
Built around a single-socket architecture, the PowerEdge R570 provides an efficient balance between processing capability, rack space and power consumption. The design allows organizations to increase computing capacity while keeping the physical footprint under control.

The server uses an Intel Xeon 6507P Granite Rapids processor running at 3.5GHz, with speeds of up to 4.3GHz and 48MB of cache. The processor provides eight cores and does not include integrated graphics, making the system well suited to server environments where dedicated graphics are not required.

Performance and Efficient Rack Deployment
The PowerEdge R570 is engineered to maximize data center productivity while supporting efficient use of rack space. Its 2U chassis provides room for substantial storage and expansion capabilities without requiring a larger server footprint.

Dell's Smart Power and Cooling approach is designed to help maintain efficient operation while supporting consistent performance. The system is also built around industry-standard open designs and DC-MHS compliance, providing flexibility for evolving infrastructure requirements.

Typical applications include:

• Virtualization environments requiring a capable single-socket server.
• Scale-out database workloads.
• Medium virtual machine density deployments.
• Virtual desktop infrastructure (VDI).
• Software-defined storage nodes.
• Data center applications where rack space and power efficiency are important.

Intel Xeon 6 Processing and DDR5 ECC Memory
This configuration includes an Intel Xeon 6507P Granite Rapids processor with eight cores, a 3.5GHz base frequency, up to 4.3GHz maximum frequency and 48MB cache. The system is equipped with 32GB of DDR5 ECC memory, providing reliable memory operation for business and enterprise server workloads.

Key hardware details include:

• Processor: Intel Xeon 6507P Granite Rapids
• Processor speed: 3.5GHz, up to 4.3GHz
• Processor cache: 48MB
• Processor cores: 8
• Memory: 32GB DDR5 ECC
• Graphics: No integrated graphics

High Capacity Hot-Plug Storage
The server is supplied with a 960GB SATA Read Intensive SSD using a 6Gbps interface and 512e format. The 12-bay 3.5-inch chassis provides additional storage flexibility and supports hot-plug drive configurations, helping simplify maintenance and future storage expansion.

Storage and chassis configuration:

• Drive: 960GB SATA Read Intensive SSD
• Interface: SATA 6Gbps
• Drive format: 512e
• Chassis: 2U with 12 x 3.5-inch drive bays
• Storage controller: PERC H965i

Reliable Power for Enterprise Server Environments
The Dell PowerEdge R570 includes dual hot-plug 1100W power supplies. The redundant power configuration is designed for data center environments where serviceability and power resilience are important.

The hot-plug design also allows supported power components to be serviced or replaced with reduced disruption to server operations.

Dell OpenManage Systems Management
Managing a large server environment can become complex, particularly as infrastructure expands. Dell OpenManage provides a range of tools for discovering, deploying, monitoring, managing, updating and securing PowerEdge servers.

PowerEdge iDRAC, OpenManage Enterprise and CloudIQ can also work together to support intelligent automation across the server lifecycle. These management technologies can help administrators streamline routine tasks, improve operational visibility and scale infrastructure more efficiently.

Security Designed for the Server Lifecycle
The PowerEdge R570 incorporates Dell's cyber-resilient architecture to help protect server infrastructure throughout its lifecycle. Security technologies include silicon root of trust, secured component verification, signed firmware, drift detection, BIOS recovery and dynamic system lockdown.

These capabilities are designed to help organizations strengthen server security and support a Zero Trust approach across their data center infrastructure.

Dell PowerEdge R570 Technical Details

• Model: Dell PowerEdge R570
• Form factor: 2U rack server
• Processor: Intel Xeon 6507P Granite Rapids
• CPU frequency: 3.5GHz, up to 4.3GHz
• Cache: 48MB
• Cores: 8
• Memory: 32GB DDR5 ECC
• Storage: 960GB SATA Read Intensive SSD
• Storage interface: SATA 6Gbps
• Drive format: 512e
• Chassis: 12 x 3.5-inch
• RAID controller: PERC H965i
• Power supplies: 2 x 1100W hot-plug
• Operating system: Not included
• Graphics: No integrated graphics
• Part Number / SKU: EMEA_PROMO_R570_SPL3

Scalable Server Infrastructure for Growing Businesses
The Dell PowerEdge R570 offers a practical combination of processing performance, storage capacity, management capabilities and power efficiency in a compact 2U chassis. Its scalable design makes it suitable for organizations building or expanding virtualization, database, VDI and software-defined storage environments.

With enterprise-focused management and security technologies, hot-plug components and a flexible rack-mounted design, the PowerEdge R570 provides a solid platform for modern data center infrastructure.

Specifications:

© 2026 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	EMEA_PROMO_R570_SPL3
Feature	Technical Specifications
Processor	One Intel Xeon 6 E-core processor with up to 144 cores
	One Intel Xeon 6 P-core processor with up to 86 cores with R1S option
Memory	16 DDR5 DIMM slots, speeds up to 6400 MT/s
	One Intel Xeon 6 E-core processor - supports RDIMM 1 TB max
	One Intel Xeon 6 P-core processor with up to 86 cores with R1S option - supports RDIMM 4 TB max
	Supports registered ECC DDR5 DIMMs only Supports registered ECC DDR5 DIMMs only
Storage controllers	Internal Controllers (RAID): PERC H365i DC-MHS, PERC H965i DC-MH, PERC H365i Adapter PERC H965i Adapter
	Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS), M.2 interposer with up to 2 x M.2 NVMe SSDs, USB
	External Controllers: PERC H965e, HBA 465e
Drive Bays	Front bays:
	Up to 12 x 3.5-inch SATA (HDD) RAID max 384 TB
	Up to 8 x 2.5-inch NVMe RAID max 491.52 TB
	Up to 8 x 2.5-inch NVMe max 491.52 TB
	Up to 8 x 2.5-inch SATA max 30.72 TB
	Up to 8 x 2.5-inch SATA/Universal max 491.52 TB
	Up to 16 x 2.5-inch SATA RAID max 61.44 TB
	Up to 24 x 2.5-inch SATA max 92.16 TB
	Up to 8 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 491.52 TB
	Up to 8 x EDSFF E3.S (cold-aisle) Gen5 NVMe 491.52 TB
	Up to 16 x EDSFF E3.S (cold-aisle) Gen5 NVMe max 983.04 TB
	Up to 16 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 983.04 TB
	Up to 32 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 1966.08 TB
	Rear bays:
	Up to 4 x EDSFF E3.S Gen5 NVMe max 245.76 TB
Power Supplies	800 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant
	1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant
	1500 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant
	1500 W 277 Vac and HVDC Titanium, hot swap redundant
	1400 W -48 VDC, hot swap redundant
	1800 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant
Cooling Options	Air cooling
Fans	Up to six hot plug fans
Dimensions	Height - 86.8 mm (3.42 inches)
	Width - 482.0 mm (18.98 inches)
	Depth - 802.38 mm (31.59 inches) with bezel
	Depth - 801.49 mm (31.55 inches) without bezel
	Depth (Cold aisle/Front I/O Configuration) - 814.5 mm (32.06 inches) without bezel
	Note: Front I/O configuration will not have a bezel.
Form Factor	2U rack server
Embedded Management	iDRAC
	iDRAC Direct
	iDRAC RESTful API with Redfish
	RACADM CLI
	iDRAC Service Module (iSM)
Bezel	Optional security bezel
Security	Cryptographically signed firmware
	Data at Rest Encryption (SEDs with local or external key mgmt)
	Secure Boot
	Secured Component Verification (Hardware integrity check)
	Secure Erase
	Silicon Root of Trust
	System Lockdown
	TPM 2.0 FIPS, CC-TCG certified
	Chassis Intrusion Detection
GPU Options	Up to 3 x 400W DW , Up to 4 x 75W SW
DPU Options	NVIDIA BlueField-3 2 x 200 GbE B3220
Ports	Front Ports
	1 x USB 2.0 Type-C (HOST/BMC Direct)
	1 x USB 2.0 Type-A (optional LCP - Secondary KVM)
	1 x Mini DisplayPort (optional LCP - Secondary KVM)
	1 x DB9 Serial (with front I/O configuration)
	1 x Dedicated BMC Ethernet port (with front I/O configuration)
	Rear Ports
	1 x Dedicated BMC Ethernet port
	2 x USB 3.1 Type-A
	1 x VGA
	Internal Port
	1 x USB 3.1 Type-A
PCIe	Up to six PCIe slots (x16 connector)
	Slot 2: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length
	Slot 3: 1 x16 Gen5 Full Height, Half Length
	Slot 4: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length or 1 x16 OCP3.0
	Slot 6: 1 x4 Gen4 Boss (optional)
	Slot 7: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length
	Slot 9: 1 x16 Gen5 Full Height, Half Length
	Slot 10: 1 x16 OCP3.0
	Slot 31: 1 x16 Gen5 Full Height, Half Length
	Slot 34: 1 x16 OCP3.0 or 1 x4 Gen4 Boss (optional)
	Slot 36: 1 x16 Gen5 Full Height, Half Length
	Slot 38: 1 x16 OCP3.0
Gen5 PCIe slots	4
OCP Network options	Up to two OCP NIC card 3.0: Two slots on the front or two slots on the rear (optional)
Embedded NIC	1 Gb dedicated BMC Ethernet port
Operating System and	Canonical Ubuntu Server LTS
Hypervisors	Microsoft Windows Server with Hyper-V
	RedHat Enterprise Linux
	SUSE Linux Enterprise Server
	VMware ESXi
