338-BSDQ

Dell Intel Xeon Bronze 3204 1.9GHz 6C/6T 9.6GT/s 8.25M Cache No Turbo No HT (85W) DDR4-2133 processor

Overview:

Intel Xeon Silver 3204 1.92GHz, 6C/6T, 9.6GT/s, 8.25M Cache, No Turbo, No HT (85W) DDR4-2133
Manufacturer part HW0W3
Dell part 338-BSDQ

The Intel Xeon 3204 1.92GHz Six Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep technology that allows tradeoffs to be made between performance and power consumption.

Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon 3204 1.92GHz Six Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.

Features:

This product is compatible with the following systems:

PowerEdge C6420
PowerEdge FC640
PowerEdge MX740C
PowerEdge R540
PowerEdge R740XD
PowerEdge XR2
PowerEdge R740
PowerEdge T440
PowerEdge R740xd2
PowerEdge T640
PowerEdge M640
PowerEdge R640
PowerEdge R440
PowerEdge M640 VRTX

Specifications:

© 2023 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	338-BSDQ
Item	Intel Xeon Bronze 3204 Processor (8.25M Cache, 1.90 GHz)
Essentials
Product Collection	2nd Generation Intel Xeon Scalable Processors
Code Name	Products formerly Cascade Lake
Vertical Segment	Server
Processor Number	3204
Status	Launched
Launch Date	Q2'19
Lithography	14 nm
Performance
# of Cores	6
# of Threads	6
Processor Base Frequency	1.90 GHz
Max Turbo Frequency	1.90 GHz
Cache	8.25 MB
# of UPI Links	2
TDP	85 W
Supplemental Information
Embedded Options Available	No
Memory Specifications
Max Memory Size (dependent on memory type)	1 TB
Memory Types	DDR4-2133
Maximum Memory Speed	2133 MHz
Max # of Memory Channels	6
ECC Memory Supported	Yes
Intel Optane DC Persistent Memory Supported	No
Expansion Options
Scalability	2S
PCI Express Revision	3
Max # of PCI Express Lanes	48
Package Specifications
Sockets Supported	FCLGA3647
TCASE	77°C
Package Size	76.0mm x 56.5mm
Advanced Technologies
Intel Deep Learning Boost (Intel DL Boost)	Yes
Intel Speed Select technology - Performance Profile	No
Intel Speed Select technology - Base Frequency	No
Intel Resource Director Technology (Intel RDT)	Yes
Intel Speed Shift Technology	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel Turbo Boost Technology	No
Intel vPro Platform Eligibility	Yes
Intel Hyper-Threading Technology	No
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel TSX-NI	Yes
Intel 64	Yes
Instruction Set Extensions	Intel SSE4.2, Intel AVX, Intel AVX2, Intel AVX-512
# of AVX-512 FMA Units	1
Enhanced Intel SpeedStep Technology	Yes
Intel Volume Management Device (VMD)	Yes
Security & Reliability
Intel AES New Instructions	Yes
Intel Trusted Execution Technology	Yes
Execute Disable Bit	Yes
Intel Run Sure Technology	No
Mode-based Execute Control (MBE)	Yes
